The Toyota Mega Cruiser is a Japanese heavy-duty off-roader powered by a 4.1-litre 15B-FTE turbo-diesel four-cylinder rated at about 153 hp and 282 lb-ft, with a 4-speed automatic and portal axles. It was built from the mid-1990s to 2001, and only 133 went to civilian buyers.
Quick answer
About 3,000 Mega Cruisers were built in total. It is 5,090 mm long, 2,170 mm wide and weighs about 2,850 kg, with up to 420 mm of ground clearance and locking differentials front, rear and centre.
Toyota Mega Cruiser specs
| Item | Spec |
|---|---|
| Engine | 15B-FTE, 4.1 L turbo-diesel inline-four |
| Power / torque | 114 kW (153 hp) / 382 Nm (282 lb-ft) |
| Transmission | 4-speed automatic with two-speed transfer case |
| Wheelbase | 3,395 mm |
| Length / width / height | 5,090 / 2,170 / 2,075 mm |
| Curb weight | About 2,850 kg |
| Load capacity | About 600 kg |
| Ground clearance | Up to 420 mm at the lowest point |
| Seating | Two front, four rear |
| Production | Mid-1990s to 2001; about 3,000 built, 133 sold to civilians |
Mega Cruiser off-road features
- Portal axles lift the axle centre for extra clearance.
- Locking differentials front, rear and centre, with a dual-range transfer case.
- Independent suspension front and rear.
- Central tire pressure system was an option.
Military and civilian versions
The BXD10 was the military version used as a High Mobility Vehicle by the Japan Self-Defense Forces. The BXD20 was the civilian version, with a standard low roof or an optional high roof. Civilian sales were small because of its price, size and Japan’s narrow streets.
Who a Mega Cruiser suits
- Collectors and expedition builders who want a rare, tough truck.
- Not a daily driver: it is wide, heavy and thirsty compared with a normal SUV.
Buying and import checks
- Confirm the chassis plate and whether it is a BXD10 or BXD20.
- Check Canadian import rules, including age, safety and emissions requirements.
- Inspect portal axles, differential locks and the tire pressure system, if fitted.
- Find a specialist for parts, since supply is limited.
Similar vehicles
Compare it with the Mercedes Unimog camper, the Toyota truck motorhome and the Toyota camper truck.
Frequently Asked Questions
What engine does the Toyota Mega Cruiser use?
It uses the 15B-FTE, a 4.1-litre turbo-diesel inline-four rated at about 153 hp and 282 lb-ft.
How many Toyota Mega Cruisers were built?
About 3,000 were built in total, and only 133 were sold to civilian buyers.
Does the Mega Cruiser have portal axles?
Yes. It uses portal axles with independent suspension and up to 420 mm of ground clearance.
What is the difference between the BXD10 and BXD20?
The BXD10 is the military version used by Japan’s Self-Defense Forces. The BXD20 is the civilian version.
Can I import a Toyota Mega Cruiser to Canada?
It depends on the vehicle’s age and compliance with Canadian import, safety and emissions rules, so check with Transport Canada first.
