Mercedes Sprinter 4WD means two different systems depending on the year. Sprinters sold in the U.S. through model year 2022 had a driver-selectable 4×4 mode. From 2023 the Sprinter uses an all-wheel-drive system, powered in the high-output version by a 211-hp, 2.0-litre diesel.
Quick answer: Mercedes Sprinter 4WD specs for the U.S. AWD cargo van: 2.0 L four-cylinder diesel, 211 hp, 332 lb-ft, 9G-TRONIC automatic, payload from about 3,350 to 5,440 lb and towing of 5,000 lb (2500) or 7,500 lb (3500XD). Canadian availability and ratings may differ, so confirm with a Mercedes-Benz Vans dealer in Canada.
4×4 versus AWD: which Sprinter do you have?
The older selectable 4×4 and the newer all-wheel-drive system are not the same thing. The third-generation Sprinter added the all-wheel-drive option for the 2023 model year in the U.S. and dropped the selectable setting. Check the model year before you compare listings or aftermarket parts.
Mercedes Sprinter 4WD specs by configuration
| AWD cargo van (U.S. specs) | Payload | Max towing | Cargo volume |
|---|---|---|---|
| 2500, 144″ standard roof | 3,858 lb | 5,000 lb | 319 cu ft |
| 3500XD, 144″ standard roof | 5,441 lb | 7,500 lb | 281 cu ft |
| 2500, 144″ high roof | 3,781 lb | 5,000 lb | 374 cu ft |
| 3500XD, 144″ high roof | 5,353 lb | 7,500 lb | 329 cu ft |
| 2500, 170″ high roof | 3,450 lb | 5,000 lb | 488 cu ft |
| 3500XD, 170″ high roof | 5,000 lb | 7,500 lb | 430 cu ft |
| 2500, 170″ extended high roof | 3,351 lb | 5,000 lb | 533 cu ft |
All of the vans above use the 1,950 cc diesel with 211 hp at 3,800 rpm and 332 lb-ft between 1,400 and 2,400 rpm, with a 9G-TRONIC automatic. Maximum GVWR is 9,050 lb for the 2500 and 11,030 lb for the 3500XD. These figures are from Mercedes-Benz Vans USA’s listing, which also had a few inconsistent entries, so confirm any number that matters with a dealer.
What to check before buying
- Weight rating: a 2500 and a 3500XD carry and tow very different loads.
- Roof and length: cargo volume swings from about 281 to 533 cubic feet.
- Year: pre-2023 vans use the older selectable 4×4 and different engines.
- Canadian version: engines, ratings and fuel economy (L/100 km) are not always the same as U.S. listings.
- Use: AWD adds traction on snow and gravel but it is not a full off-road system, and it adds weight and cost.
Prices vary by configuration and dealer, so check a current Canadian quote. If you are building a camper, our Mercedes Unimog camper specs and Toyota camper truck guide cover other options for rough-road travel.
This guide uses manufacturer information. We have not driven or tested the van.
Mercedes Sprinter 4WD FAQ
Does the Mercedes Sprinter come with 4WD?
Yes. Through model year 2022 the U.S. Sprinter had a selectable 4×4 system, and from 2023 it has an all-wheel-drive system.
What engine does the 2026 Sprinter AWD use?
A 2.0-litre four-cylinder diesel rated at 211 hp and 332 lb-ft, with a 9G-TRONIC automatic transmission.
How much can a Sprinter AWD tow?
Mercedes-Benz Vans USA lists 5,000 lb for 2500 models and 7,500 lb for 3500XD models.
How much can a Sprinter AWD carry?
Payload runs from about 3,350 lb to 5,440 lb depending on the 2500 or 3500XD, wheelbase and roof height.
Is Sprinter AWD the same as 4×4?
No. The older 4×4 was a driver-selectable system, while the newer AWD system is automatic.
